AL5811
Document number: DS35255 Rev. 1 - 2
3 of 13
January 2013
© Diodes Incorporated
NEW PROD
UC
T
AL5811
Package Thermal Data
Package
θ
JC
Thermal Resistance
Junction-to-case
(Note 5)
θ
JA
Thermal Resistance
Junction-to-Ambient
(Note 5)
P
DIS
T
A
= +25°C,
T
J
= +125°C
MSOP-8EP
37
85°C/W (Note 6)
1.2W
U-DFN3030-6
13
71°C/W (Note 7)
1.40W
Notes:
5. Dominant conduction path via exposed pad.
6. Test condition for MSOP-8EP: Device mounted on FR-4 PCB (51mm x 51mm 2oz copper, minimum recommended pad layout on top layer and
thermal vias to bottom layer ground plane. For better thermal performance, larger copper pad for heat-sink is needed.
7. Test condition for U-DFN3030-6: Device mounted on FR-4 PCB (51mm x 51mm 2oz copper, minimum recommended pad layout on top layer and
thermal vias to bottom layer with maximum area ground plane. For better thermal performance, larger copper pad for heat-sink is needed
Recommended Operating Conditions
(@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Min
Max
Unit
V
CC
Supply Voltage Range Relative to GND Pin
3.5
60
V
V
LED
OUT Voltage Range Relative to GND Pin
1.0
60
I
LED
LED Pin Current (Note 8)
10
75
mA
T
A
Operating Ambient Temperature Range
-40
+125
°C
Note:
8. Maximum LED current is also limited by ambient temperature and power dissipation such that junction temperature should
be kept less than or equal 125°C.
Electrical Characteristics
(@T
A
= +25°C, V
CC
= 3.5V, V
LED
= 1.0 (Note 9), R
SET
= 15kΩ, unless otherwise specified.)
Symbol Parameter
Conditions
Min
Typ
Max
Unit
V
RSET
R
SET
Voltage
T
A
= -40°C to +125°C
0.5 V
I
LED
I
LED
Current Accuracy
R
SET
= 37.5kΩ
T
A
= +25°C
18 20 22
mA
R
SET
= 10kΩ
70 75 80
R
SET
= 15kΩ
47 50 53
T
A
= -40°C to +125°C
46 54
REG
LINE
LED Current Line Regulation
V
CC
= 3.5V to 60V
T
A
= +25°C
0.25 %
I
CC
Supply Current
3.5V ≤ V
CC
≤ 60V
T
A
= +25°C
200
300
µA
T
A
= -40°C to +125°C
350
I
LEAK
LED Pin Leakage Current
V
CC
= 60V; V
LED
= 60V
RSET = Open Circuit
T
A
= +125°C
1
µA
T
SHDN
Thermal Shutdown
155
°C
T
HYS
Thermal Shutdown Hysteresis
20
°C
Note:
9. All voltages unless otherwise stated are measured with respect to GND pin.
