AP7331
300mA, LOW QUIESCENT CURRENT, FAST TRANSIENT
LOW DROPOUT LINEAR REGULATOR
AP7331
Document number: DS31914 Rev. 3 - 2
3 of 13
January 2011
© Diodes Incorporated
Absolute Maximum Ratings
Symbol
Parameter
Ratings
Units
ESD HBM
Human Body Model ESD Protection
6
kV
ESD MM
Machine Model ESD Protection
400
V
V
IN
Input
Voltage
7
V
EN
Voltage
V
IN
+ 0.3
V
Continuous Load Current
Internal Limited
T
OP
Operating Junction Temperature Range
-40 ~ 125
°C
T
ST
Storage Temperature Range
-65 ~150
°C
P
D
Power Dissipation (Note 2)
SOT25 640
mW
DFN2020-6 740 mW
T
J
Maximum Junction Temperature
150
°C
Recommended Operating Conditions
Symbol
Parameter
Min
Max
Unit
V
IN
Input voltage
2
6
V
I
OUT
Output Current (Note 3)
0
300
mA
T
A
Operating Ambient Temperature
-40
85
°C
Notes:
2. Ratings apply to ambient temperature at 25°C
3. The device maintains a stable, regulated output voltage without a load current.
