AP7165
600mA LOW DROPOUT REGULATOR WITH POK
AP7165
Document number: DS31270 Rev. 7 - 2
8 of 15
www.diodes.com
March 2012
© Diodes Incorporated
Typical Performance Characteristics (cont.)
Current Limit Protection
(V
OUT
= 1.8V)
Time (50µs/div)
Current Limit & Short Circuit Protection
(V
OUT
= 0.8V)
Time (500µs/div)
Short Circuit Protection (V
OUT
= 1.8V)
Time (2ms/div)
Short Circuit Recovery (V
OUT
= 1.8V)
Time (50µs/div)
INPUT VOLTAGE (V)
Short Circuit Current vs. Input Voltage
2.0 2.5 3.0 3.5 4.0 4.5 5.0
S
H
O
R
T
C
IR
C
U
IT
C
U
R
R
E
N
T
(mA
)
420
410
400
370
360
350
390
380
V = 1.2V
OUT
V = 1.2V
OUT
TEMPERATURE (°C)
Short Circuit Current vs. Temperature
-50 -25 0 25 50 75
S
H
O
R
T
C
IR
C
U
IT
C
U
R
R
EN
T
(mA
)
500
450
350
350
400
V
OUT
500mV/di
I
OUT
500mA/di
Current Limit Protection
Short Circuit Protection
V
OUT
500mV/div
I
OUT
500mA/div
V
OUT
500mV/div
I
OUT
500mA/div
V
OUT
500mV/div
I
OUT
1A/div
Current Limit Protection
Short Circuit Protection
