600mA LOW DROPOUT LINEAR REGULATOR AP1117M
Data Sheet
1A ULDO REGULATOR WITH ENABLE AP2318A
5
May. 2011 Rev 2. 0 BCD Semiconductor Manufacturing Limited
Recommended Operating Conditions
Note 1: Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to the device.
These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated
under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Maximum Ratings" for extended periods
may affect device reliability.
Note 2: Absolute maximum ratings indicate limits beyond which damage to the component may occur. Electrical specifica-
tions do not apply when operating the device outside of its operating ratings. The maximum allowable power dissipation is a
function of the maximum junction temperature, T
J
(Max)
,
the junction-to-ambient thermal resistance,
θ
JA,
and the ambient tem-
perature, T
A.
The maximum allowable power dissipation at any ambient temperature is calculated using: P
D
(max)=(T
J
(Max) -
T
A
)/
θ
JA.
Exceeding the maximum allowable power dissipation will result in excessive die temperature, and the regulator will
go into thermal shutdown.
Parameter Symbol Value Unit
Input Voltage V
IN
15 V
Operating Junction Temperature T
J
150 o
C
Storage Temperature Range T
STG
-65 to 150 o
C
Lead Temperature (Soldering, 10sec) T
LEAD
260 o
C
Thermal Resistance, Junction to Ambient (Note 2)
θ
JA
DFN-3x3-8 120
o
C/W
PSOP-8 108
ESD (Human Body Model) ESD 3000 V
ESD (Machine Model) ESD 600 V
Parameter Symbol Min Max Unit
Input Voltage V
IN
2.5 12 V
Enable Voltage V
EN
12 V
Operating Junction Temperature Range T
J
-40 125 o C
Absolute Maximum Ratings (Note 1)
