ULTRA LOW QUIESCENT CURRENT CMOS LDO AP2138/2139
Data Sheet
4
Jul. 2012 Rev. 2. 3 BCD Semiconductor Manufacturing Limited
Package
Temperature
Range
Condition Part Number Marking ID
Packing
Type
SOT-23-3 -40 to 85 o C
AP2138N-1.2TRG1 GA3 Tape & Reel
1.4V AP2138N-1.4TRG1 GG1 Tape & Reel
1.5V AP2138N-1.5TRG1 GG2 Tape & Reel
1.8V AP2138N-1.8TRG1 GG4 Tape & Reel
2.5V AP2138N-2.5TRG1 GG5 Tape & Reel
2.8V AP2138N-2.8TRG1 GG6 Tape & Reel
3.0V AP2138N-3.0TRG1 GG3 Tape & Reel
3.3V AP2138N-3.3TRG1 GG7 Tape & Reel
3.6V AP2138N-3.6TRG1 GG8 Tape & Reel
4.0V AP2138N-4.0TRG1 GE9 Tape & Reel
SOT-89 -40 to 85 o C
1.2V(R) AP2138R-1.2TRG1 G42C Tape & Reel
1.4V (R) AP2138R-1.4TRG1 G42D Tape & Reel
1.5V (R) AP2138R-1.5TRG1 G42E Tape & Reel
1.8V (R) AP2138R-1.8TRG1 G42F Tape & Reel
2.5V (R) AP2138R-2.5TRG1 G42G Tape & Reel
2.8V (R) AP2138R-2.8TRG1 G42H Tape & Reel
3.0V (R) AP2138R-3.0TRG1 G42J Tape & Reel
3.3V (R) AP2138R-3.3TRG1 G42K Tape & Reel
Circuit Type
Package
N: SOT-23-3
G1: Green
AP213X -
TR: Tape and Reel
Ordering Information
1.2V
1.4: Fixed Output 1.4V
1.5: Fixed Output 1.5V
2.8: Fixed Output 2.8V
8: AP2138
9: AP2139
K: SOT-23-5
A: Active High
with Built-in Resistor
Blank: No Enable Function
3.0: Fixed Output 3.0V
3.3: Fixed Output 3.3V
1.8: Fixed Output 1.8V
2.5: Fixed Output 2.5V
1.2: Fixed Output 1.2V
R/RA: SOT-89
3.6: Fixed Output 3.6V
4.0: Fixed Output 4.0V
