Peak 3A CMOS LDO Regulator with Enable and Power Good AP2132A
Mar. 2012 Rev 1.0 BCD Semiconductor Manufacturing Limited
5
Absolute Maximum Ratings (Note 1)
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Parameter Symbol Min Max Unit
Input Voltage V
IN
1.4 5.5 V
Input Voltage for Controlling
Circuit
V
CTRL
4.5 5.5 V
Operating Ambient Temperature
Range
T
A
-40 85 °C
Parameter Symbol Value Unit
Input Voltage
Input Voltage for Controlling Circuit V
IN
V
CTRL
6.0 V
Enable Input Voltage V
EN
-0.3 to 6.0 V
Thermal Resistance (No Heatsink) θ
JA
130 ºC/W
Operating Junction Temperature T
J
150 ºC
Storage Temperature Range T
STG
-65 to 150 ºC
Lead Temperature (Soldering, 10sec) T
LEAD
260 ºC
ESD (Machine Model) 200 V
ESD (Human Body Model) 2000 V
