HIGH SPEED, EXTREMELY LOW NOISE LDO REGULATOR AP2121
Data Sheet
Mechanical Dimensions (Continued)
CSP-4 (P 0.4) Unit: mm(inch)
0.960(0.038)
1.060(0.042)
Pin 1 Mark
0.
94
0(
0.
03
7)
1.
04
0(
0.
04
1)
0.400(0.016)
TYP.
0.
40
0(
0.
01
6)
TY
P
.
Φ 0.270(0. 011)
TYP.
B A
1
2
0. 550(0.022)
0. 650(0.026) 0.180(0. 007)
0.220(0. 009)
