0.5A to 2.0A High-side Power Distribution Switches AP2822
Dec. 2012 Rev 1. 1 BCD Semiconductor Manufacturing Limited
5
Ordering Information
AP2822 -
Circuit Type
Package
Temperature
Range
Condition Part Number Marking ID
Packing
Type
SOT-23-5 -40 to 85 °C
Active High
(Continuous 0.5A)
AP2822AKTR-G1 GCQ Tape & Reel
Active Low
(Continuous 0.5A)
AP2822BKTR-G1 GCR Tape & Reel
Active High
(Continuous 1.0A)
AP2822CKTR-G1 GCS Tape & Reel
Active Low
(Continuous 1.0A)
AP2822DKTR-G1 GCT Tape & Reel
Active High
(Continuous 1.5A)
AP2822EKTR-G1 GCU Tape & Reel
Active Low
(Continuous 1.5A)
AP2822FKTR-G1 GCV Tape & Reel
Active High
(Continuous 2.0A)
AP2822GKTR-G1 GCW Tape & Reel
Active Low
(Continuous 2.0A)
AP2822HKTR-G1 GCZ Tape & Reel
Package
K/KA/KB/KE: SOT-23-5
Condition
A: Active High (Continuous 0.5A)
B: Active Low (Continuous 0.5A)
C: Active High (Continuous 1.0A)
D: Active Low (Continuous 1.0A)
E: Active High (Continuous 1.5A)
F: Active Low (Continuous 1.5A)
G: Active High (Continuous 2.0A)
H: Active Low (Continuous 2.0A)
G1: Green
TR: Tape & Reel
