AP2181D/AP2191D
Typical Performance Characteristics
V
EN
90%
V
OUT
T
D(ON)
10%
T
D(OFF)
50% 50%
T
R
10%
90%
T
F
V
EN
90%
V
OUT
T
D(ON)
10%
T
D(OFF)
50% 50%
T
R
10%
90%
T
F
Figure 1 Voltage Waveforms: AP2181D (left), AP2191D (right)
All Enable Plots are for AP2181D Active Low
Turn-On Delay and Rise Time
100µs/div
Turn-Off Delay and Fall Time
100µs/div
Turn-On Delay and Rise Time
500µs/div
Turn-Off Delay and Fall Time
500µs/div
Vout
2V/div
Ven
5V/div
CL = 1µF
TA = +25°C
RL = 10Ω
Vout
2V/div
Ven
5V/div
CL = 1µF
TA = +25°C
RL = 10Ω
Vout
2V/div
Ven
5V/div
CL = 120µF
TA = +25°C
RL = 10Ω
Vout
2V/div
Ven
5V/div
CL = 120µF
TA = 25°C
RL = 10Ω
