DUAL 1A LOW DROPOUT POSITIVE REGULATOR
AP1121 Rev. 5
1 of 7
FEBRUARY 2009
©
Diodes Incorporated
Lead-free
•
1.3V maximum dropout at full load current
•
Fast transient response
•
Output current limiting for each channel
•
Built-in thermal shutdown for each channel
•
Good noise rejection
•
Dual output ch1 = 3.3V, ch2 = 2.5V
(ch2 = 1.8V for version B)
•
SOP-8L: Available in “Green” Molding Compound
(No Br, Sb)
Lead Free Finish/ RoHS Compliant (Note 1)
AP1121 is a low dropout positive regulator which provides 1A
output current capability. The product is specifically designed to
provide well-regulated supply for low voltage IC applications such
as high-speed bus termination and low current 3.3V/2.5V or
3.3V/1.8V logic supply. AP1121 is guaranteed to have <1.3V
dropout at full load current making it ideal to provide well
regulated outputs dual channels with up to 18V input supply.
• PC
peripheral
• Communication
Package
S : SOP-8L
Packing
Lead Free
L : Lead Free
13 : Tape & Reel
Vout
A : CH1=3.3V
CH2=2.5V
B : CH1=3.3V
CH2=1.8V
G : Green
AP 1121 X S X - 13
Device
Package
Code
Packaging
(Note 2)
13” Tape and Reel
Quantity
Part Number Suffix
AP1121XSL-13
S SOP-8L
2500/Tape
&
Reel
-13
AP1121XSG-13
S SOP-8L
2500/Tape
&
Reel
-13
