AP1120
DUAL 1A LOW DROPOUT POSITIVE REGULATOR
AP1120 Rev. 2
1 of 7
FEBRUARY 2009
©
Diodes Incorporated
Lead-free
•
1.3V maximum dropout at full load current
•
Fast transient response
•
Output current limiting for each channel
•
Built-in thermal shutdown each channel
•
Good noise rejection
•
Dual output ch1=3.3V, ch2=2.5V
(1.8V for B version)
•
Lead Free Package: SOP-8L
•
Lead Free Finish/ RoHS Compliant (Note 1)
AP1120 series are low dropout positive regulator to provide
1A output current capability. The product is specifically designed
to provide well-regulated supply for low voltage IC applications
such as high-speed bus termination and low current 3.3V/2.5V or
3.3V/1.8V logic supply. AP1120 series are guaranteed to have
<1.3V dropout at full load current making it ideal to provide well
regulated outputs dual channels with up to 18V input supply.
• PC
peripheral
• Communication
AP 1120 S X L - 13
13 : Tape & Reel
Lead Free
L : Lead Free
Packing
Vout
Blank : CH1=3.3V
CH2=2.5V
B : CH1=3.3V
CH2=1.8V
Package
S : SOP-8L
Device
Package
Code
Packaging
(Note 2)
13” Tape and Reel
Quantity
Part Number Suffix
AP1120SXL-13
S SOP-8L
2500/Tape
&
Reel
-13
Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
2. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be on found our website at
Features
General Description
Applications
Ordering Information
