AP6508
500kHz 21V 3A SYNCHRONOUS DC/DC BUCK CONVERTER
AP6508
Document number: DS33437 Rev. 5 - 2
3 of 14
www.diodes.com
October 2011
© Diodes Incorporated
NEW PROD
UC
T
Absolute Maximum Ratings (Note 2)
Symbol Parameter Rating Unit
V
IN
Supply Voltage 22 V
V
SW
Switch Node Voltage -0.3 to 23 V
V
BS
Bootstrap Voltage VSW + 6 V
V
FB
Feedback Voltage –0.3V to +6 V
V
EN
Enable/UVLO Voltage –0.3V to +6 V
V
COMP
Comp Voltage –0.3V to +6 V
T
ST
Storage Temperature -65 to +150 °C
T
J
Junction Temperature +150 °C
T
L
Lead Temperature +260 °C
ESD Susceptibility (Note 3)
HBM Human Body Model 3 kV
MM Machine Model 300 V
Thermal Resistance (Note 4)
Symbol Parameter Rating Unit
θ
JA
Junction to Ambient 52 °C/W
θ
JC
Junction to Case 11 °C/W
Recommended Operating Conditions (Note 5)
Symbol Parameter Min Max Unit
V
IN
Supply Voltage 4.5 21 V
T
A
Operating Ambient Temperature Range -40 +85 °C
Notes: 2. Stresses greater than the 'Absolute Maximum Ratings' specified above, may cause permanent damage to the device. These are stress ratings
only; functional operation of the device at these or any other conditions exceeding those indicated in this specification is not implied. Device
reliability may be affected by exposure to absolute maximum rating conditions for extended periods of time.
3. Semiconductor devices are ESD sensitive and may be damaged by exposure to ESD events. Suitable ESD precautions should be taken when
handling and transporting these device.
4. Test condition for SO-8EP: Device mounted on 2"*2" FR-4 substrate PC board, 2oz copper, with minimum recommended pad on top layer and
thermal vias to bottom layer ground plane.
5. The device function is not guaranteed outside of the recommended operating conditions.
