AP5101

1.5A Step-Down Converter with 1.4MHz Switching

Frequency

AP5101

Document number: DS32258 Rev. 1 - 2

13 of 15

www.diodes.com

July 2010

NEW PROD

Ordering Information

AP5101 S G - 13

Package

Packing

Green

G : Green

S : SO-8

13 : Tape & Reel

Device

Package

Code

Packaging

(Note 6)

13” Tape and Reel

Quantity

Part Number Suffix

AP5101SG-13

SO-8

2500/Tape & Reel

-13

Note: 6. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf.

Marking Information

( Top View )

AP5101

YY WW X X

Logo

Part No

WW : Week : 01~52;

YY : Year : 10, 11, 12~

G : Green

X : Internal Code

52 represents 52 and 53 week
