Data Sheet
340kHz, 2A Synchronous DC-DC Buck Converter AP3502F
Oct. 2012 Rev. 1. 3 BCD Semiconductor Manufacturing Limited
7
Typical Performance Characteristics (Continued)
T
A
=25ºC, V
IN
=12V, V
OUT
=3.3V, unless otherwise noted.
Figure 8. High-side Switch On-resistance Figure 9. Low-side Switch On-resistance
vs. Case Temperature vs. Case Temperature
Figure 10. Output Ripple (I
OUT
=2A) Figure 11. Load Transient (I
OUT
=1A to 2A)
-60 -40 -20 0 20 40 60 80 100 120 140
40
60
80
100
120
140
160
180
200
Hi
gh
-s
id
e
Swi
tch
On-resistan
ce (m
Ω
)
Case Temperature ( o C)
-60 -40 -20 0 20 40 60 80 100 120 140
40
60
80
100
120
140
160
Lo
w-s
ide S
w
itc
h
O
n
-r
es
is
tanc
e
(m
Ω
)
Case Temperature ( o C)
V
IN_AC
200mV/div
V
OUT_AC
20mV/div
I
L
1A/div
V
SW
10V/div
Time 2 μs/div
V
OUT_AC
100mV/div
I
OUT
1A/div
Time 200 μs/div
