Preliminary Datasheet
1.5MHz Synchronous Step-down DC-DC Converter AP3410
Mar. 2013 Rev. 1. 1 BCD Semiconductor Manufacturing Limited
4
Ordering Information
AP3410 -
G1: Green
Circuit Type
Package
Temperature
Range
Part Number
Marking
ID
Packing Type
SOT-23-5 -40 to 85ºC AP3410KTR-G1 GHW Tape & Reel
DFN-2×2-6 -40 to 85ºC AP3410DNTR-G1 CJ Tape & Reel
BCD Semiconductor's Pb-free products, as designated with "G1" suffix in the part number, are RoHS compliant
and green.
Absolute Maximum Ratings (Note 1)
Parameter Symbol Value Unit
Input Voltage for the MOSFET Switch V
IN
0 to 6.0 V
Enable Input Voltage V
EN
-0.3 to V
IN
+0.3 V
LX Pin Switch Current I
LX
1.8 A
Power Dissipation (on PCB, T
A
=25°C) P
D
SOT-23-5 0.4
W
DFN-2×2-6 1.89
Thermal Resistance (Junction to Ambient,
Simulation)
θ
JA
SOT-23-5 250
ºC/W
DFN-2×2-6 53
Thermal Resistance (Junction to Case,
Simulation)
θ
JC
SOT-23-5 130 ºC/W
Operating Junction Temperature T
J
155 ºC
Storage Temperature T
STG
-55 to 150 ºC
Operating Temperature T
OP
-40 to 85 ºC
ESD (Machine Model) V
MM
200 V
ESD (Human Body Model) V
HBM
2000 V
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
TR: Tape & Reel K: SOT-23-5
DN: DFN-2Ч2-6
