150kHz 3A BUCK DC-DC CONVERTER AP3003

Data Sheet

3

Aug. 2008 Rev. 1. 2

BCD Semiconductor Manufacturing Limited

Functional Block Diagram

Figure 3. Functional Block Diagram of AP3003

ON/OFF

FEEDBACK

V

IN

OUTPUT

GND

+

_

+

_

+

_

+

_

START UP

2.5V

REGULATOR

1.23V

REFERENCE

LATCH

150KHz

OSC

DRIVER

&

INV

THERMAL

SHUTDOWN

EA

COMP

COMP

COMP

2.5V

Bias

Current

Frequency Shift

220

mV

200

mV

1:100

R2

R1

1

2

3

4

5

R1=2.49k

Ω R2=4.18kΩ

R1=2.49k

Ω R2=7.57kΩ

R1=2.49k

Ω R2=21.8kΩ

For 3.3V

5V

12V

ADJ

4.4

R1=Open R2=0
