150kHz 3A BUCK DC-DC CONVERTER AP3003
Data Sheet
12
Aug. 2008 Rev. 1. 2 BCD Semiconductor Manufacturing Limited
Figure 20. Typical Application of AP3003-5.0V
Figure 19. Typical Application of AP3003-3.3V
L1: Sumida CDRH127/LDNP-220MC or Equivalent
L1: Sumida CDRH127/LDNP-220MC or Equivalent
Typical Application
+ +
L1
22µH
D1
1N5822
C
OUT
ON/OFF GND
V
IN OUTPUT
FEEDBACK
220µF
C
IN
470µF
Regulated
DC Output
3A Load
AP3003-3.3V
4
2
5 3
1
+ +
L1
22
µH
D1
1N5822
C
OUT
ON/OFF GND
V
IN OUTPUT
FEEDBACK
220
µF
C
IN
470
µF
12V
Unregulated
DC Input
Regulated
DC Output
3A Load
AP3003-5.0V
4
2
5 3
1
