AP1635
PWM/PFM DUAL MODE STEP-DOWN DC/DC
CONVERTER
AP1635 Rev. 4
1 of 8
FEBRUARY 2009
©
Diodes Incorporated
Lead-free
•
Input voltage range: 2.2V~5V (V
OUT
type)
•
Oscillator frequency: 700KHz (Typ.)
•
Internal reference: 1.0V (Typ.)
•
High efficiency: 93% (Typ.)
•
Current limit and thermal shutdown protection
•
Lead Free Package: SOP-8L
•
SOP-8L: Available in “Green” Molding Compound
(No Br, Sb)
•
Lead Free Finish/ RoHS Compliant (Note 1)
The AP1635 series are multi-functional step-down DC/DC
converters with built-in speed, low ON resistance drivers. It is
capable to deliver more than 1.2A output current with external
coil, diode and capacitor.
Output voltage is set-up by the external resistors. (±2.5%
accuracy). The 700KHz AP1635 that can work out with small
value external components comes out more compact board.
The device switches to and works under PFM mode with light
loads. It keeps at high efficiency for both light loads and large
output current.
AP1635 can be soft-start with a proper capacitor connected
between CE/SS pin and ground. The stand-by current is less
than 6uA when CE/SS pin is at “LOW” status. The device is
forced to switch off as the voltage at that pin is lower than the
stipulated voltage.
Applications
•
Electronic Information Organizers
• Palmtops
•
Cellular and portable phones
•
Portable Audio Systems
•
Various Multi-function Power Supplies
Ordering Information
AP 1635 S X - 13
Package
Packing
Lead Free
13 : Tape & Reel
G : Green
S : SOP-8L
L : Lead Free
Device
Package
Code
Packaging
(Note 2)
13” Tape and Reel
Quantity
Part Number Suffix
AP1635SL-13 S
SOP-8L
2500/Tape
&
Reel
-13
AP1635SG-13 S
SOP-8L
2500/Tape
&
Reel
-13
Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
2. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
Features
General Description
