AP1530
18V 3A 300KHz BUCK CONVERTER
AP1530 Rev. 7 5 of 12 NOVEMBER 2009
DS31092 www.diodes.com © Diodes Incorporated
Electrical Characteristics
(V
IN
= 12V, T
A
=25°C, unless otherwise specified)
Symbol Parameter Conditions Min Typ. Max Unit
V
FB
Feedback Voltage I
OUT
=0.1A 0.784 0.8 0.816 V
I
FB
Feedback Bias Current I
OUT
=0.1A - 0.1 0.5 µA
I
SW
Switch Current -- 3.5 - - A
I
SHDN
Current Consumption During
Power Off
V
EN
=0V - 10 - µA
∆V
OUT
/V
IN
Line Regulation V
IN
=5V~18V - 1 2 %
∆V
OUT
/V
OUT
Load Regulation I
OUT
=0.1 to 3A - 0.2 0.5 %
f
OSC
Oscillation Frequency Measure waveform at SW pin 240 300 360 kHz
f
OSC1
Frequency of Current Limit or
Short Circuit Protection
Measure waveform at SW pin - 50 - kHz
V
IH EN Pin Input Voltage
Evaluate oscillation at SW pin 2.0 - -
V
V
IL
Evaluate oscillation stop at SW pin - - 0.8
I
ENH EN Pin Input Leakage Current
-- - 20 - µA
I
ENL
-- - -10 - µA
I
OCSET
OCSET Pin Bias Current -- 75 90 105 µA
T
SS
Soft-Start Time -- 0.3 2 5 ms
T
SHDN
Thermal shutdown threshold - 150 - °C
T
HYS
Thermal shutdown hysteresis - 55 - °C
R
DSON
Internal MOSFET R
DS(ON)
V
IN
=5V, V
FB
=0V - 110 150
m Ω
V
IN
=12V, V
FB
=0V - 70 100
EFFI Efficiency
V
IN
=12V, V
OUT
= 5V
I
OUT
=3A
- 92 - %
θ
JA
Thermal Resistance
Junction-to-Ambient
SOP-8L (Note 3) - 134 - o C/W
θ
JC
Thermal Resistance
Junction-to-Case
SOP-8L (Note 3) - 22 -
o
C/W
Notes: 3. Test condition SOP-8L: Device mounted on FR-4 substrate 2oz copper, minimum recommended pad layout, and single side.
For better thermal performance, please arrange larger copper pad of layout for heatsink.
