AP1506
150KHz, 3A PWM BUCK DC/DC CONVERTER
AP1506
Document number: DS31015 Rev. 7 - 2
6 of 14
June 2010
© Diodes Incorporated
Electrical Characteristics
(Continued)
Specifications with boldface type are for full operating temperature range, the other type are for T
J
= 25ºC.
Symbol
Parameter
Conditions
V
Min
Typ.
V
Max
Unit
AP1506-ADJ
FB
V
Output
Feedback
5V < V
IN
< 22V
0.2A < I
LOAD
< 3A
V
OUT
programmed for
3V
1.193 1.23 1.267
V
1.18
-
1.28
η
Efficiency V
IN
= 12V, I
LOAD
= 3A
-
74
-
%
AP1506-3.3V
OUT
V
Output
Voltage
5.5V < V
IN
< 22V
0.2A < I
LOAD
< 3A
3.168 3.3 3.432
V
3.135
-
3.465
η
Efficiency V
IN
= 12V, I
LOAD
= 3A
-
75
-
%
AP1506-5V
OUT
V
Output
Voltage
8V < V
IN
< 22V
0.2A < I
LOAD
< 3A
4.8 5 5.2
V
4.75
-
5.25
η
Efficiency V
IN
= 12V, I
LOAD
= 3A
-
80
-
%
AP1506-12V
OUT
V
Output
Voltage
15V < V
IN
< 22V
0.2A < I
LOAD
< 3A
11.52 12 12.48
V
11.4
-
12.6
η
Efficiency V
IN
= 16V, I
LOAD
= 3A
-
89
-
%
