AP1506

150KHz, 3A PWM BUCK DC/DC CONVERTER

AP1506

Document number: DS31015 Rev. 7 - 2

12 of 14

www.diodes.com

June 2010

© Diodes Incorporated

Marking Information

(1) TO263-5L

1506- XX

Output Type:

1506 : ADJ
1506-33 : 3.3V
1506-50 : 5.0V
1506-12 : 12V

Logo

ID code

Year:

( Top view )

"08" = 2008

"07" = 2007

YY WW X X

Xth week: 01~52

~

L : Lead Free
G : Green

(2) TO220-5L(R)

1506- XX

Output Type:

1506 : ADJ

1506-33 : 3.3V
1506-50 : 5.0V
1506-12 : 12V

Logo

ID code

Year:

"08" = 2008

"07" = 2007

YY WW X X

Xth week: 01~52

~

L : Lead Free
G : Green

( Top view )
