Diodes AP3107Z - Manual (Page 4)

AP3107Z
Document number: DS36677 Rev. 2 - 1
4 of 11
www.diodes.com
November 2013
© Diodes Incorporated
AP3107Z
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(Note 4)
Parameter Symbol Value Unit
Supply Voltage V
CC
30 V
Input Voltage to HV V
HV
600 V
GATE Output Current I
GATE
500 mA
Input Voltage to FB, SENSE V
FB
, V
SENSE
-0.3 to 7 V
Thermal Resistance
(Junction to Ambient)
θ
JA
186 ºC/W
Power dissipation at T
A
<25ºC P
D
550 mW
Operating Junction Temperature T
J
-40 to +150 ºC
Storage Temperature T
STG
+150 ºC
ESD (Human Body Model) – 3000 V
ESD (Machine Model) – 300 V
Note 4 : Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating Conditions” is not implied.
Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Parameter Symbol Min Max Unit
Supply Voltage V
CC
10 25 V
Ambient Temperature T
A
-40 +85 ºC
