Preliminary Datasheet
HIGH VOLTAGE GREEN MODE PWM CONTROLLER AP3106
Sep. 2011 Rev. 1. 0 BCD Semiconductor Manufacturing Limited
5
Absolute Maximum Ratings (Note 1)
Parameter Symbol Value Unit
Power Supply Voltage V
CC
30 V
Input Voltage to High Voltage Pin
(HV)
V
HV
600 V
GATE Output Current I
GATE
500 mA
Input Voltage to FB, SENSE V
FB
, V
SENSE
-0.3 to 7 V
Thermal Resistance
(Junction to Ambient)
θ
JA
186 °C/W
Power Dissipation at T
A
<25ºC P
D
550 mW
Operating Junction Temperature T
J
-40 to 150 °C
Storage Temperature T
STG
150 °C
ESD (Human Body Model) 3000 V
ESD (Machine Model) 300 V
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Parameter Symbol Min Max Unit
Supply Voltage V
CC
10 25 V
Ambient Temperature T
A
-40 85 °C
