DUAL OP AMP AND VOLTAGE REFERENCE AP4310/A
6
Jan. 2013 Rev. 1. 8 BCD Semiconductor Manufacturing Limited
Data Sheet
Parameter Conditions Min Typ Max Unit
Op Amp 2 Section (V
CC
=5V, V
O
=1.4V, T
A
=25 o C, unless otherwise noted)
Input Offset Voltage
T
A
=25 o C 0.5 3
mV
T
A
=-40 to 105
o
C 5
Input Offset Voltage Temperature
Drift
T
A
=-40 to 105 o C 7 µV/ o C
Input Offset Current T
A
=25 o C 2 30 nA
Input Bias Current T
A
=25 o C 20 150 nA
Input Voltage Range V
CC
=0 to 36V 0 V
CC
-1.5 V
Common Mode Rejection Ratio T
A
=25
o
C, V
CM
=0 to 3.5V 70 85 dB
Large Signal Voltage Gain V
CC
=15V, R
L
=2k Ω, V
O
=1.4 to 11.4V 85 100 dB
Power Supply Rejection Ratio V
CC
=5 to 30V 70 90 d Β
Output Current
Source V
CC
=15V, V
ID
=1V, V
O
=2V 20 40 mA
Sink V
CC
=15V, V
ID
=-1V, V
O
=2V 5 20 mA
Output Voltage Swing (High) V
CC
=30V, R
L
=10k Ω, V
ID
=1V 27 28 V
Output Voltage Swing (Low) V
CC
=30V, R
L
=10k Ω, V
ID
=-1V 17 100 mV
Slew Rate
V
CC
=18V, R
L
=2k Ω, A
V
=1,
V
IN
=0.5 to 2V, C
L
=100pF
0.2 0.5 V/ µ s
Unity Gain Bandwidth V
CC
=30V, R
L
=2k Ω, C
L
=100pF 0.7 1.0 MHz
Electrical Characteristics (Continued)
Operating Conditions: V
CC
= + 5V, T
A
=25 o C unless otherwise specified.
