D5V0F1U2LP
Document number: DS36163 Rev. 2 - 2
3 of 4
www.diodes.com
April 2014
© Diodes Incorporated
D5V0F1U2LP
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
0
t, TIME ( s)
Figure 3 Pulse Waveform

20 40 60
100
50
0
Peak Value I
pp
Half Value I /2
pp
8x20 Waveform
as defined by R.E.A. I
, PE
AK
P
U
LS
E
CURR
ENT
(
%
I
)
Pp
p
P
0.01
0.1
1
10
100
1000
300 400 500 600 700 800 900 1000 1100
Figure 4 Typical Forward Characteristics
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
F
I
, I
N
ST
ANT
A
NE
O
U
S FORW
ARD
CURRENT
(
m
A)
F
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
T = -55°C
A
1
10
100
0 1 2 3 4 5 5.5
I
, L
EAK
AGE
CURRENT
(
n
A)
R
V , REVERSE VOLTAGE (V)
R
Figure 5 Typical Reverse Characteristics
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
T = -55°C
A
0.2
0.25
0.3
0.35
0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5
V , REVERSE VOLTAGE (V)
R
Figure 6 Total Capacitance vs. Reverse Voltage
C
, T
O
TAL
C
A
P
A
C
IT
A
N
C
E (
pF
)
T
0.4
0.5
0.6
f = 1MHz
Note 8
0.45
0.55
0.1
0.15
X1-DFN1006-2
Dim Min Max Typ
A 0.47 0.53 0.50
A1 0 0.05 0.03
b 0.45 0.55 0.50
D 0.95 1.075 1.00
E 0.55 0.675 0.60
e - - 0.40
L 0.20 0.30 0.25
R 0.05 0.15 0.10
All Dimensions in mm
L
E b
R
e
D
A1
A
