D24V0L1B2LPS
Document number: DS36505 Rev. 2 - 2
3 of 4
www.diodes.com
April 2014
© Diodes Incorporated
D24V0L1B2LPS
ADVAN
CE I
N
F
O
RM
ATI
O
N
NEW PROD
UC
T
80 40 20 0
t, TIME (µs)
Figure 3 Pulse Waveform
100
50
0
I,
P
EA
K
P
U
LS
E
C
U
R
R
EN
T
(%
I
)
PP
P
P
t = 8µs
r
Peak Value I
PP
Half Value I
PP
/2
8x20 Waveform
as defined by R.E.A. t
p
I
, INST
AN
TA
NEOUS R
EVERS
E
CURRE
NT
(
nA)
R
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
Figure 4 Typical Reverse Characteristics
1
10
0 5 10 15 20 25
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
T = -55°C
A
V , REVERSE VOLTAGE (V)
R
Figure 5 Typical Capacitance
C
, T
O
TAL
C
A
P
A
C
IT
A
N
C
E (
p
F
)
T
f = 1MHz
0
1
2
3
4
5
6
7
8
9
10
0 5 10 15 20 25
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for the latest version.
U-DFN1006-2/SWP
Dim Min Max Typ
A 0.47 0.53 0.50
A1 0.0 0.05 0.03
b 0.45 0.55 0.50
c 0.55 REF
D 0.95 1.05 1.00
E 0.55 0.65 0.60
h 0.17 REF
k 0.37 REF
L 0.25 0.35 0.30
All Dimensions in mm
P i n # 1 I D
S e a t i n g P l a n e
A 1
A
E
D
b ︵2 x ︶
L ︵2 x ︶ k
h
c
