2N7002
60V SOT23 N-channel enhancement mode MOSFET
Summary
Description
A small signal MOSFET for general purpose switching applications.
Features
•
Fast switching speed
•
Low gate drive capability
•
SOT23 package
Applications
•
General switching applications
Ordering information
Device marking
702
V
(BR)DSS
R
DS(on)
(
⍀)
I
D
(A)
60
7.5 @ V
GS
= 10V
0.5
7.5 @ V
GS
= 5V
0.05
Device
Reel size
(inches)
Tape width
(mm)
Quantity per reel
2N7002
7
8
3,000
D
S
G
D
Top view
S
G
