Diodes DCX4710H User Manual
Page 2

DS30871 Rev. 6 - 2
2 of 7
www.diodes.com
DCX4710H
© Diodes Incorporated
Sub-Component Device – Pre-Biased PNP Transistor (Q1)
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Collector-Base Voltage
V
CBO
-50
V
Collector-Emitter Voltage
V
CEO
-50
V
Supply Voltage
V
CC
-50
V
Input Voltage
V
IN
+6 to -40
V
Output Current (dc)
I
C(max)
-100
mA
Sub-Component Device – Pre-Biased NPN Transistor (Q2)
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Collector-Base Voltage
V
CBO
50
V
Collector-Emitter Voltage
V
CEO
50
V
Supply Voltage
V
CC
50
V
Input Voltage
V
IN
-10 to +40
V
Output Current (dc)
I
C(max)
100
mA
Electrical Characteristics: Pre-Biased PNP Transistor (Q1)
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
OFF CHARACTERISTICS
Collector-Base Cut Off Current
I
CBO
⎯
⎯
-100 nA
V
CB
= -50V, I
E
= 0
Collector-Base Breakdown Voltage
V
(BR)CBO
-50
⎯
V
I
C
= -10
μA, I
E
= 0
Collector-Emitter Breakdown Voltage
V
(BR)CEO
-50
⎯
V
I
C
= -4mA, I
B
= 0
B
Input Off Voltage
V
I(OFF)
⎯
⎯
-0.3
V
V
CE
= -5V, I
C
= -100
μA
Output Off Current
I
O(OFF)
⎯
⎯
-0.5
μA
V
CC
= -50V, V
I
= 0V
ON CHARACTERISTICS
DC Current Gain
h
FE
80
⎯
⎯
⎯
V
CE
= -5V, I
C
= -5mA
Collector-Emitter Saturation Voltage
V
CE(sat)
⎯
⎯
-0.25
V
I
C
= -10mA, I
B
= -0.3mA
B
Output On Voltage
V
O(ON)
⎯
-0.1
-0.3
V
I
O
/I
I
= -10mA/-0.5mA
Input On Voltage (Load is present)
V
I(ON)
-1.4
-0.9
⎯
V
V
O
= -0.3V, I
C
= -2mA
Input Current
I
I
⎯
⎯
-0.88
mA
V
I
= -5V
Input Resistor +/- 30% (Base)
ΔR1
7
10
13
K
Ω
⎯
Pull-up Resistor (Base to Vcc supply)
R2
32
47
62
K
Ω
⎯
Resistor Ratio
Δ(R2/R1)
20
⎯
20
%
⎯
SMALL SIGNAL CHARACTERISTICS
Transition Frequency (gain bandwidth product)
f
T
⎯
250
⎯
MHz
V
CE
= -10V, I
E
= -5mA,
f = 100MHz
*Pulse Test: Pulse width, tp<300 uS, Duty Cycle, d<=0.02
