DDC(xxxx)U
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
For R1 only devices: DDC113TU & DDC143TU & DDC114TU
Characteristic Symbol Min Typ Max Unit Test Condition
Collector-Base Breakdown Voltage BV
CBO
50   V I
C
= 50μA
Collector-Emitter Breakdown Voltage BV
CEO
50   V I
C
= 1mA
Emitter-Base Breakdown Voltage BV
EBO
5   V I
E
= 50μA
Collector Cutoff Current I
CBO
  0.5 μA V
CB
= 50V
Emitter Cutoff Current I
EBO
  0.5 μA V
EB
= 4V
Collector-Emitter Saturation Voltage V
CE(sat)
  0.3 V
I
C
/I
B
= 2.5mA / 0.25mA DDC143TU
I
C
/I
B
= 1mA / 0.1mA DDC114TU
I
C
/I
B
= 10mA / 1mA DDC113TU
DC Current Transfer Ratio h
FE
100 250 600  I
C
= 1mA, V
CE
= 5V
Input Resistor (R
1
) Tolerance R
1
-30  +30 % 
Gain-Bandwidth Product (Note 7) f
T
 250  MHz V
CE
= 10V, I
E
= -5mA, f = 100MHz
For R1, R2 devices: DDC124EU & DDC144EU & DDC114YU & DDC123JU & DDC114EU
Characteristic Symbol Min Typ Max Unit Test Condition
Input Voltage
DDC124EU
DDC144EU
DDC114YU
DDC123JU
DDC114EU
V
l(off)
0.5
0.5
0.3
0.5
0.5 1.1
1.1


1.1

V
V
CC
= 5V, I
O
= 100μA
DDC124EU
DDC144EU
DDC114YU
DDC123JU
DDC114EU
V
l(on)

1.9
1.9


1.9
3.0
3.0
1.4
1.1
3.0 V
O
= 0.3, I
O
= 5mA
V
O
= 0.3, I
O
= 2mA
V
O
= 0.3, I
O
= 1mA
V
O
= 0.3, I
O
= 5mA
V
O
= 0.3, I
O
= 10mA
Output Voltage
DDC124EU
DDC144EU
DDC114YU
DDC123JU
DDC114EU
V
O(on)
 0.1 0.3 V
I
O
/I
l
= 10mA / 0.5mA
I
O
/I
l
= 10mA / 0.5mA
I
O
/I
l
= 5mA / 0.25mA
I
O
/I
l
= 5mA / 0.25mA
I
O
/I
l
= 10mA / 0.5mA
Input Current
DDC124EU
DDC144EU
DDC114YU
DDC123JU
DDC114EU
I
l
 
0.36
0.18
0.88
3.6
0.88
mA V
I
= 5V
Output Current I
O(off)
  0.5 μA V
CC
= 50V, V
I
= 0V
DC Current Gain
DDC124EU
DDC144EU
DDC114YU
DDC114YUQ
DDC123JU
DDC114EU
G
l
56
68
68
80
80
30
  
V
O
= 5V, I
O
= 5mA
V
O
= 5V, I
O
= 5mA
V
O
= 5V, I
O
= 10mA
V
O
= 5V, I
O
= 5mA
V
O
= 5V, I
O
= 10mA
V
O
= 5V, I
O
= 5mA
Input Resistor (R
1
) Tolerance R
1
-30  +30 % 
Resistance Ratio Tolerance R
2
/R
1
-20  +20  
Gain-Bandwidth Product (Note 7) f
T
 250  MHz V
CE
= 10V, I
E
= 5mA, f = 100MHz
Note: 7. Transistor - For Reference Only
