DCX(xxxx)U
Document number: DS30347 Rev. 16 - 2
2 of 12
www.diodes.com
November 2013
© Diodes Incorporated
DCX(xxxx)U
Marking Information
Date Code Key
Year 2010 2011 2012 2013 2014 2015 2016 2017
Code X Y Z A B C D E
Month Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec
Code 1 2 3 4 5 6 7 8 9 O N D
Absolute Maximum Ratings NPN Section
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Supply Voltage V
CC
50 V
Input Voltage
DCX124EU
DCX144EU
DCX114YU
DCX123JU
DCX114EU
DCX143TU
DCX143EU
DCX114TU
V
IN
-10 to +40
-10 to +40
-6 to +40
-5 to +12
-10 to +40
-5V max
-10 to +30
-5V max
V
Output Current
DCX124EU
DCX144EU
DCX114YU
DCX123JU
DCX114EU
DCX143TU
DCX143EU
DCX114TU
I
O
30
30
70
100
50
100
100
100
mA
Output Current I
C
(Max) 100 mA
Absolute Maximum Ratings PNP Section
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Supply Voltage V
CC
50 V
Input Voltage
DCX124EU
DCX144EU
DCX114YU
DCX123JU
DCX114EU
DCX143TU
DCX143EU
DCX114TU
V
IN
+10 to -40
+10 to -40
+6 to -40
+5 to -12
+10 to -40
+5V max
+10 to -30
+5V max
V
Output Current
DCX124EU
DCX144EU
DCX114YU
DCX123JU
DCX114EU
DCX143TU
DCX143EU
DCX114TU
I
O
-30
-30
-70
-100
-50
-100
-100
-100
mA
Output Current I
C
(Max) -100 mA
CXX = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: X = 2010)
M = Month (ex: 9 = September)
CXX YM
