APT13005
Datasheet Number:DS36308 Rev.1 - 2
5 of 6
July 2013
© Diodes Incorporated
A Product Line of
Diodes Incorporated
APT13005
Package Outline Dimensions
rsion.
TO220F-3
TO220AB Type C (TO220-3(2))
Note:
For high voltage applications, the appropriate industry sector guidelines should be considered with regards to voltage spacing between terminals.
TO220F-3
Dim
Min
Max Typ
A
4.300
4.900 -
A2
2.520 2.920 -
A3
2.350 2.900 -
b
0.550 0.900 -
b1
1.000 1.400 -
b2
1.100 1.500 -
c
0.450 0.600 -
D
9.70 10.30 -
E
14.70 16.00 -
e
-
- 2.540
L
12.50
13.50 -
L1
2.790
4.500 -
X
6.90
7.10 -
Y
3.000
3.400 -
Y1
3.370
3.900 -
ø
3.000
3.550 -
All Dimensions in mm
TO220AB
Type C
Dim
Min Max Typ
A
- -
4.500
A2
- -
2.400
A3
- -
1.300
b
0.700 0.900
-
b1
- -
1.270
c
0.400 0.600
-
D
9.800 10.200
-
E
9.000 9.400
-
e
- -
2.54
H1
6.300 6.700
-
L
12.600 13.600
-
L1
9.600 10.600
-
Y
- -
11.100
Ø
3.560 3.640
-
All Dimensions in mm
D
X
Y
Y 1
E
L
L 1
b 1
b 2
b
e
e
A 3
A
A 2
c
ø
3 °
D
Y
E
L
L 1
H 1
3 °
3 °
A
A 2
c
e
e
A 3
1 . 3 0
1 . 7 0
0 . 6 0
ø
b
b 1
