APT13003E
Datasheet Number: DS36304 Rev.1 - 2
5 of 6
July 2013
© Diodes Incorporated
A Product Line of
Diodes Incorporated
APT13003E
Package Outline Dimensions
rsion.
TO92 Type C
TO126
Note:
For high voltage applications, the appropriate industry sector guidelines should be considered with regards to voltage spacing between terminals.
TO92 Type C
Dim
Min
Max Typ
A
3.30
3.70 -
A2
1.10 1.40 -
b
0.38 0.55 -
c
0.36 0.51 -
D
4.40 4.70 -
D1
3.430 -
-
E
4.30 4.70 -
e
-
- 1.27
e2
2.440 2.640
-
h
0.00
0.38 -
L
14.10 14.50
-
L1
12.50 14.50
-
L3
2.50
3.50
-
ø
-
1.60 -
All Dimensions in mm
TO126
Dim
Min
Max Typ
A
2.400
2.900 -
A2
1.060 1.500 -
b
0.660 0.860 -
b1
1.170 1.470 -
c
0.400 0.600 -
D
7.400 8.200 -
E
10.60 11.20 -
e
-
- 2.280
e1
-
- 4.560
h
0.00
0.30 -
L
14.50
15.90 -
L1
1.700
2.100 -
Y
3.600
3.900 -
ø
3.100
3.550 -
All Dimensions in mm
D
E
Y
L
L 1
b
b 1
e 1
e
A
A 2
h
c
ø
E
L
D
A
e
e
E J E C T I O N M A R K
b 1
T A P E D
B U L K
c
E
L 1
E J E C T I O N M A R K
L 2
L 3
D 1
A 2
e 2
e 2
ø
h
b
AMMO
