APT13003E
Electrical Characteristics
(@T A = +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Collector-Emitter Breakdown Voltage BV CES
700 — — V I C = 100µA, V BE = 0V
Collector-Emitter Breakdown Voltage BV
CEO
465 — — V I
C
= 100µA
Emitter-Base Breakdown Voltage BV EBO
9 — — V I E = 100µA
Collector Cutoff Current I
CEV
— — 10 µA V
CE
= 700V, V
BE
= -1.5V
DC current transfer Static ratio (Note 7) h
FE
15
13
5
—
17
—
—
30
25
—
—
— I
C
= 0.3A, V
CE
= 2V
I
C
= 0.5A, V
CE
= 2V
I
C
= 1.0A, V
CE
= 2V
Collector-Emitter Saturation Voltage (Note 7) V
CE(sat)
—
— 0.17
0.29 0.3
0.4
V
I
C
= 0.5A, I
B
= 0.1A
I
C
= 1A, I
B
= 0.25A
Base-Emitter Saturation Voltage (Note 7) V
BE(sat)
—
— —
— 1.0
1.2
V
I
C
= 0.5A, I
B
= 0.1A
I
C
= 1A, I
B
= 0.25A
Output Capacitance C
ob
— 16 — pF V
CB
= 10V, f = 0.1MHz
Transition Frequency f
T
4 — — MHz I
C
= 0.1A, V
CE
= 10V
Turn-on Time with Resistive Load t
on
— 0.3 1
µs
I C = 1A,V CC = 125V, I B1 = 0.2A,
I
B2
= -0.2A, t
p
= 25µs
Storage Time with Resistive Load t s
— 1.8 3
Fall Time with Resistive Load t
f
— 0.28 0.4
Note: 7. Measured under pulsed conditions. Pulse width ≤ 300μs. Duty cycle ≤ 2%.
