2DA1201Y
Document number: DS35644 Rev: 3 - 2
4 of 7
August 2012
© Diodes Incorporated
A Product Line of
Diodes Incorporated
2DA1201Y
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
-120
-
- V
I
C
= -100µA
Collector-Emitter Breakdown Voltage (Note 10)
BV
CEO
-120
-
- V
I
C
= -10mA
Emitter-Base Breakdown Voltage
BV
EBO
-7
-
- V
I
E
= -100µA
Collector-Emitter Cut-off Current
I
CES
- -
-100
nA
V
CE
= -120V
Collector Cut-off Current
I
CBO
- -
-100
nA
V
CB
= -120V
Emitter Cut-off Current
I
EBO
- -
-100
nA
V
EB
= -5V
Static Forward Current Transfer Ratio (Note 10)
h
FE
120 - 240 -
I
C
= -100mA, V
CE
= -5V
Collector-Emitter Saturation Voltage (Note 10)
V
CE(sat)
- - -1 V
I
C
= -500mA, I
B
= -50mA
Base-Emitter Turn-On Voltage (Note 10)
V
BE(on)
- - -1 V
I
C
= -500mA, V
CE
= -5V
Transition Frequency
f
T
- 160 - MHz
I
C
= -100mA, V
CE
= -5V
Output Capacitance
C
OBO
15 pF
V
CB
= -10V, I
E
= 0, f = 1MHz
Delay Time
t
(d)
- 62 - ns
V
CC
= -80V, I
C
= -100mA,
I
B1
= -10mA, I
B2
= 20mA
Rise Time
t
(r)
- 50 - ns
Storage Time
t
(s)
- 440 - ns
Fall Time
t
(f)
- 42 - ns
Note:
10. Measured under pulsed conditions. Pulse width
≤ 300µs. Duty cycle ≤ 2%.
