2DA1201Y
Document number: DS35644 Rev: 3 - 2
2 of 7
www.diodes.com
August 2012
© Diodes Incorporated
A Product Line of
Diodes Incorporated
2DA1201Y
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage V
CBO
-120 V
Collector-Emitter Voltage V
CEO
-120 V
Emitter-Base Voltage V
EBO
-7 V
Continuous Collector Current I
C
-800 mA
Peak Pulse Current (Note 6) I CM
-3 A
Base Current I
B
-160 mA
Thermal Characteristics
Characteristic Symbol Value Unit
Power Dissipation (Note 7) P
D
1.5 W
Thermal Resistance, Junction to Ambient (Note 7) R θJA 83 °C/W
Thermal Resistance, Junction to Leads (Note 8) R θJL 18.3 °C/W
Operating and Storage Temperature Range T
J,
T
STG
-55 to +150
°C
ESD Ratings
(Note 9)
Characteristic Symbol Value Unit JEDEC Class
Electrostatic Discharge - Human Body Model ESD HBM ≥ 8,000 V 3B
Electrostatic Discharge - Machine Model ESD MM ≥ 400 V C
Notes: 6. Measured under pulsed conditions. Pulse width ≤ 300µs. Duty cycle ≤ 2%.
7. For a device surface mounted on 25mm X 25mm FR4 PCB with high coverage of single sided 1 oz copper, in still air conditions.
8. Thermal resistance from junction to solder-point (at the end of the collector lead).
9. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
