BSR33
Da
tasheet Number: DS33017 Rev. 5 - 2
4 of 7
November 2013
© Diodes Incorporated
BSR33
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ.
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
-90
– – V
I
C
= -100μA
Collector-Emitter Breakdown Voltage (Note 11)
BV
CEO
-80
– – V
I
C
= -10mA
Emitter-Base Breakdown Voltage
BV
EBO
-5
– – V
I
E
= -100μA
Collector Cutoff Current
I
CBO
– –
-100
-50
nA
µA
V
CB
= -60V
V
CB
= -60V, T
J
= +150°C
DC current transfer Static ratio (Note 11)
h
FE
30
100
50
–
–
–
–
300
–
–
I
C
= -100µA, V
CE
= -5V
I
C
= -100mA, V
CE
= -5V
I
C
= -500mA, V
CE
= -5V
Collector-Emitter Saturation Voltage (Note 11)
V
CE(sat)
–
–
–
–
-0.25
-0.5
V
I
C
= -150mA, I
B
= -15mA
I
C
= -500mA, I
B
= -50mA
Base-Emitter Saturation Voltage (Note 11)
V
BE(sat)
– –
-1.0
-1.2
V
I
C
= -150mA, I
B
= -15mA
I
C
= -500mA, I
B
= -50mA
Transitional Frequency
f
T
100 – – MHz
I
C
= -50mA, V
CE
= -10V
f = 35MHz
Output capacitance
C
obo
– – 20 pF
V
CB
= -10V, f = 1MHz
Input Capacitance
C
ibo
– –
120 pF
V
CB
= -0.5V, f = 1MHZ
Turn-On Time
T
on
– –
500 ns
V
CC
=-20V, I
C
= -100mA
I
B1
=I
B2
= -5mA
Turn-Off Time
T
off
– –
650 ns
Note:
11. Measured under pulsed conditions. Pulse width ≤ 300μs. Duty cycle ≤ 2%.
