Page 3
BZX84C2V4W - BZX84C39W
0
10
20
30
0
I,
Z
E
N
E
R
C
U
R
R
EN
T
(m
A
)
Z
V , ZENER VOLTAGE (V)
Fig. 3 Typical Zener Breakdown Characteristics
Z
10
20
30
40
C
, T
O
T
A
L
C
A
P
A
CIT
A
NCE
(
p
F
)
T
10
100
1,000
10
100
1
V , NOMINAL ZENER VOLTAGE (V)
Fig. 4 Typical Total Capacitance vs. Nominal Zener Voltage
Z
T = 25 °C
J
V = 1V
R
V = 2V
R
V = 1V
R
V = 2V
R
Ordering Information
(Notes 2 & 7)
Part Number
Case
Packaging
(Type Number)-7-F*
SOT-323
3000/Tape & Reel
* Add “-7-F” to the appropriate type number in Electrical Characteristics Table on Page 2 example: 6.2V Zener = BZX84C6V2W-7-F.
Notes:
7. For packaging details, go to our w.
Marking Information
xxx
YM
xxx = Product Type Marking Code
(See Electrical Characteristics Table)
YM = Date Code Marking
Y = Year (ex: N = 2002)
M = Month (ex: 9 = September)
Date Code Key
Year
1998
1999
2000
2001
2002
2003
2004
2005
2006
2007
2008
2009
2010
2011
2012
Code
J
K
L
M
N
P
R
S
T
U
V
W
X
Y
Z
Month
Jan
Feb
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
Nov
Dec
Code 1 2 3 4 5 6 7 8 9 O N D
Package Outline Dimensions
A
M
J
L
D
F
B C
H
K
G
TOP VIEW
SOT-323
Dim
Min Max
A
0.25 0.40
B
1.15 1.35
C
2.00 2.20
D
0.65 Nominal
F
0.30 0.40
G
1.20 1.40
H
1.80 2.20
J
0.0 0.10
K
0.90 1.00
L
0.25 0.40
M
0.10 0.18
α
0° 8°
All Dimensions in mm
BZX84C2V4W - BZX84C39W
Document number: DS30066 Rev. 15 - 2
3 of 4
www.diodes.com
May 2008
© Diodes Incorporated
