BAV70LP
Document number: DS31597 Rev. 4 - 2
2 of 4
January 2012
© Diodes Incorporated
BAV70LP
NEW PROD
UC
T
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Unit
Non-Repetitive Peak Reverse Voltage
V
RM
100 V
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
75 V
RMS Reverse Voltage
V
R(RMS)
53 V
Forward Continuous Current (Note 4)
I
FM
300 mA
Average Rectified Output Current (Note 4)
I
O
150 mA
Repetitive Peak Forward Current
I
FRM
450 mA
Non-Repetitive Peak Forward Surge Current
@ t = 1.0
μs
@ t = 1.0s
I
FSM
2.0
1.0
A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Power Dissipation (Note 4)
P
D
400 mW
Thermal Resistance Junction to Ambient Air (Note 4)
R
θJA
312
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Max
Unit
Test
Condition
Reverse Breakdown Voltage (Note 5)
V
(BR)R
75
⎯
V
I
R
= 2.5
μA
Forward Voltage
V
F
⎯
0.715
0.855
1.0
1.25
V
I
F
= 1.0mA
I
F
= 10mA
I
F
= 50mA
I
F
= 150mA
Reverse Current (Note 5)
I
R
⎯
2.5
50
30
25
μA
μA
μA
nA
V
R
= 75V
V
R
= 75V, T
J
= 150
°C
V
R
= 25V, T
J
= 150
°C
V
R
= 20V
Total Capacitance
C
T
⎯
2.0 pF
V
R
= 0, f = 1.0MHz
Reverse Recovery Time
t
rr
⎯
4.0 ns
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
, R
L
= 100
Ω
Notes:
4. Part mounted on FR-4 board with recommended pad layout, which can be found on our websit
5. Short duration pulse test used to minimize self-heating effect.
