BAV3004W
Document number: DS30371 Rev. 12 - 2
2 of 4
May 2012
© Diodes Incorporated
BAV3004W
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
V
RRM
350 V
Working Peak Reverse Voltage
DC Blocking Voltage
V
RWM
V
R
300 V
RMS Reverse Voltage
V
R(RMS)
212 V
Forward Continuous Current
I
FM
225 mA
Repetitive Peak Forward Current
I
FRM
625 mA
Non-Repetitive Peak Forward Surge Current
@ t = 1.0
μs
@ t = 1.0s
I
FSM
4.0
1.0
A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Power Dissipation (Note 6)
P
D
400 mW
Thermal Resistance Junction to Ambient Air (Note 6)
R
θJA
312
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Reverse Breakdown Voltage (Note 7)
V
(BR)R
350
⎯
⎯
⎯
⎯
V
I
R
= 150
μA
Forward Voltage
V
FM
⎯
0.78
0.93
1.03
0.87
1.0
1.25
V
I
F
= 20mA
I
F
= 100mA
I
F
= 200mA
Leakage Current (Note 7)
I
RM
⎯
30
35
100
100
nA
μA
V
R
= 240V, T
J
= 25
°C
V
R
= 240V, T
J
= 150
°C
Total Capacitance
C
T
⎯
1.0 5.0 pF
V
R
= 0, f = 1.0MHz
Reverse Recovery Time
t
rr
⎯
⎯
50 ns
I
F
= I
R
= 30mA,
I
rr
= 3.0mA, R
L
= 100
Ω
Notes:
6. Valid provided that terminals are kept at ambient room temperature.
7. Short duration pulse test used to minimize self-heating effect.
400
T , AMBIENT TEMPERATURE, (°C)
Fig. 1 Power Derating Curve
A
P
,
P
O
WE
R
DIS
S
IP
A
T
IO
N (
m
W
)
D
200
100
300
0
500
0
100
200
Note 6
0
400
800
1,200
1,600
2,000
I,
I
N
S
T
A
N
T
A
N
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
E
N
T
(A
)
F
m
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
Fig. 2 Typical Forward Characteristics
F
100
1.0
10
0.1
0.01
1,000
