BAV116WS
Document number: DS35981 Rev. 2 - 2
3 of 4
www.diodes.com
September 2013
© Diodes Incorporated
BAV116WS
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for latest version.
10 20 30 40 50 60 70 80
V , INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 3 Typical Reverse Characteristics
R
I
, INS
TA
N
TA
NEOU
S
REVE
RSE CUR
RENT
(
µ
A)
R 0.0001
0.001
0.01
V , DC REVERSE VOLTAGE (V)
Fig. 4 Total Capacitance vs. Reverse Voltage
R
C
, T
O
TA
L C
A
P
A
CIT
A
NCE
(p
F
)
T
f=1MHz
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
0 10 20 30 40
SOD323
Dim Min Max
A 0.25 0.35
B 1.20 1.40
C 2.30 2.70
H 1.60 1.80
J 0.00 0.10
K 1.0 1.1
L 0.20 0.40
M 0.10 0.15
 0° 8°
All Dimensions in mm
Dimensions Value (in mm)
Z 3.75
G 1.05
X 0.65
Y 1.35
C 2.40
K
L
M J
C
H
B A
Z
X
C
G Y
