BAV116W
SURFACE MOUNT LOW LEAKAGE DIODE
Features
•
Surface Mount Package Ideally Suited for Automated Insertion
•
Very Low Leakage Current
•
Lead, Halogen and Antimony Free, RoHS Compliant
"Green" Device (Notes 3 and 4)
Mechanical Data
•
Case: SOD-123
•
Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020D
•
Terminals: Solderable per MIL-STD-202, Method 208
•
Lead Free Plating (Matte Tin Finish annealed over Alloy 42
leadframe)
•
Polarity: Cathode Band
•
Marking Information: See Page 2
•
Ordering Information: See Page 2
•
Weight: 0.01 grams (approximate)
TOP VIEW
SOD-123
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
130
V
RMS Reverse Voltage
V
R(RMS)
90
V
Forward Continuous Current
I
FM
215
mA
Repetitive Peak Forward Current
I
FRM
500
mA
Non-Repetitive Peak Forward Surge Current
@ t = 1.0
μs
@ t = 1.0ms
@ t = 1.0s
I
FSM
4.0
1.0
0.5
A
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Power Dissipation (Note 2)
P
D
250
mW
Thermal Resistance Junction to Ambient Air (Note 2)
R
θJA
500
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
Reverse Breakdown Voltage (Note 1)
V
(BR)R
130
130
⎯
⎯
⎯
⎯
V
I
R
= 100
μA
I
R
= 100
μA, T
J
=125
°C
Forward Voltage
V
F
⎯
⎯
0.90
1.0
1.1
1.25
1.0
V
I
F
= 1.0mA, T
J
= 25
°C
I
F
= 10mA, T
J
= 25
°C
I
F
= 50mA, T
J
= 25
°C
I
F
= 150mA, T
J
= 25
°C
I
F
= 10mA, T
J
= 125
°C
Leakage Current (Note 1)
I
R
⎯
⎯
5.0
80
nA
nA
V
R
= 75V, T
J
= 25
°C
V
R
= 75V, T
J
= 125
°C
Total Capacitance
C
T
⎯
2.4
5
pF
V
R
= 0, f = 1.0MHz
Reverse Recovery Time
t
rr
⎯
⎯
3.0
μs
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
, R
L
= 100
Ω
Notes:
1. Short duration pulse test used to minimize self-heating effect.
2. Part mounted on FR-4 board with recommended pad layout, which can be found on page 3 or our website at
http://www.diodes.com/datasheets/ap02001.pdf
3. No purposefully added lead. Halogen and Antimony Free.
4. Product manufactured with Data Code V9 (week 33, 2008) and newer are built with Green Molding Compound. Product manufactured prior to Date
Code V9 are built with Non-Green Molding Compound and may contain Halogens or Sb
2
O
3
Fire Retardants.
BAV116W
Document number: DS30291 Rev. 11 - 2
1 of 3
