BAS116LP3
Document number: DS35241 Rev. 6 - 2
3 of 4
April 2013
© Diodes Incorporated
BAS116LP3
NEW PROD
UC
T
I
, I
N
ST
A
N
TA
NEO
U
S REVER
SE
CU
RRENT (
nA
)
R
0.1
1
10
100
0
10
20 30
40
50
60
70
80 90 100
V , INSTANTANEOUS REVERSE VOLTAGE (V)
Figure 3 Typical Reverse Characteristics
R
T = 125ºC
A
T = -55ºC
A
T = 85ºC
A
T = 25ºC
A
T = 150ºC
A
1
10
100
V , DC REVERSE VOLTAGE (V)
Figure 4 Typical Total Capacitance vs. Reverse Voltage
R
C
, T
O
TAL
C
A
P
A
C
IT
AN
C
E (
pF)
T
0.4
0.8
1.2
1.6
0
2.0
f = 1MHz
Package Outline Dimensions
Bottom View
Suggested Pad Layout
X3-DFN0603-2
Dim
Min
Max Typ
A
0.27
0.35 0.30
A1
0.00
0.03 0.02
b
0.19
0.29 0.24
D
0.595 0.645 0.62
E
0.295 0.345 0.32
e
-
- 0.355
L
0.14
0.24 0.19
All Dimensions in mm
Dimensions
Value (in mm)
C
0.380
X
0.230
Y
0.300
Z
0.610
Z
Y (2x)
X (2x)
C
L (2x)
E
b (2x)
D
A1 (2x)
A
e
