1N4148WS / BAV16WS
Document number: DS30097 Rev. 20 - 2
2 of 4
March 2012
© Diodes Incorporated
1N4148WS / BAV16WS
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Unit
Non-Repetitive Peak Reverse Voltage (Note 7)
V
RM
100 V
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
75 V
RMS Reverse Voltage
V
R(RMS)
53 V
Forward Continuous Current
I
FM
300 mA
Average Rectified Output Current
I
O
150 mA
Non-Repetitive Peak Forward Surge Current
@ t = 1.0
μs
@ t = 1.0s
I
FSM
2.0
1.0
A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Power Dissipation (Note 6)
P
D
200 mW
Thermal Resistance Junction to Ambient Air (Note 6)
R
θJA
625
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Max
Unit
Test
Condition
Reverse Breakdown Voltage (Note 7)
V
(BR)R
75
⎯
V
I
R
= 1.0
μA
Forward Voltage
V
FM
⎯
0.715
0.855
1.0
1.25
V
I
F
= 1.0mA
I
F
= 10mA
I
F
= 50mA
I
F
= 150mA
Peak Reverse Current (Note 7)
I
RM
⎯
1.0
50
30
25
μA
μA
μA
nA
V
R
= 75V
V
R
= 75V, T
J
= 150
°C
V
R
= 25V, T
J
= 150
°C
V
R
= 20V
Total Capacitance
C
T
⎯
2.0 pF
V
R
= 0, f = 1.0MHz
Reverse Recovery Time
t
rr
⎯
4.0 ns
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
, R
L
= 100
Ω
Notes:
6. Part mounted on FR-4 PC board with recommended pad layout, which can be found on our website 7. Short duration pulse test used to minimize self-heating effect.
0
100
0
25
50
75
125
100
150
P
,
P
O
WE
R
DISS
IP
A
T
IO
N
(mW
)
D
T , AMBIENT TEMPERATURE ( C)
Fig. 1 Power Derating Curve
A
°
300
200
Note 6
250
150
50
0.1
1
0.01
0.001
0
1.5
1.0
0.5
I,
I
N
S
T
AN
T
ANE
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
F
