BYP57 / BYP58
Electrical characteristics (at T
amb
= 25°C unless otherwise stated)
Parameter Symbol Min. Typ. Max. Unit Test contitions
Forward
voltage BYP57-75...800
BYP58-75...800
V
F
- 1.0 1.1 V
I
F
= 35 A,
measuring time
10ms (half-sine
wave)
Forward
voltage
(information
values)
BYP57-75...800
BYP58-75...800
V
F
- - 1.2 V I
F
= 50 A,
BYP57-75...150
BYP58-75...150
- - 3
BYP57-200...800
BYP58-200...800
I
RRM
- - 1.5
mA
T
J
= 140°C, at
V
RRM
BYP57-75...400
BYP58-75...400
- - 0.25
Reverse
current
BYP57-500...800
BYP58-500...800
I
RRM
- - 0.1
mA at V
RRM
Threshold voltage (information
value)
V
(FO)
- 0.66 - V T
J
= 175°C
Slope resistance (information
value)
r
F
- 5.75 - mΩ T
J
= 175°C
Options: Electrical characteristics for parallel connecting
(at T
amb
= 25°C unless otherwise stated)
Option Parameter Symbol Min. Typ. Max. Unit Test contitions
1 Forward voltage
difference in one
category of forward
voltage
∆V
F
- - 0.05 V I
F
= 35 A, measuring
time 10ms (half-sine
wave)
2 Reverse current in one
category of forward
voltage (only for
BYP57-300…800 and
BYP58-300…800) I
R
- - 0.01 mA at V
RRM
