BYP53 / BYP54
Electrical characteristics
(at T
amb
= 25°C unless otherwise stated)
Parameter Symbol
Min.
Typ.
Max.
Unit
Test
contitions
Forward
voltage
BYP53-75...800
BYP54-75...800
V
F
- 0.95
1.1
V
I
F
= 25 A,
measuring time
10ms (half-sine
wave)
Forward
voltage
(information
values)
BYP53-75...800
BYP54-75...800
V
F
- -
1.2
V
I
F
= 35 A,
BYP53-75...150
BYP54-75...150
- - 3
BYP53-200...800
BYP54-200...800
I
RRM
- -
1.5
mA
T
J
= 140°C, at
V
RRM
BYP53-75...400
BYP54-75...400
- -
0.25
Reverse
current
BYP53-500...800
BYP54-500...800
I
RRM
- -
0.1
mA at
V
RRM
Threshold voltage (information
value)
V
(FO)
- 0.66 - V
T
J
= 175°C
Slope resistance (information
value)
r
F
- 5.75 -
mΩ T
J
= 175°C
Options: Electrical characteristics for parallel connecting
(at T
amb
= 25°C unless otherwise stated)
Option Parameter Symbol
Min.
Typ.
Max.
Unit
Test
contitions
1 Forward
voltage
difference in one
category of forward
voltage
∆V
F
- -
0.05
V
I
F
= 25 A, measuring
time 10ms (half-sine
wave)
2
Reverse current in one
category of forward
voltage (only for
BYP53-300…800 and
BYP54-300…800)
I
R
- -
0.01
mA
at
V
RRM
Issue 4 – September 2006
4
