BYP53 / BYP54
Absolute maximum ratings (at T
amb
= 25°C unless otherwise stated)
Parameter Symbol Unit Test condition
BYP53-75 BYP54-75 75
BYP53-100 BYP54-100 100
BYP53-150 BYP54-150 150
BYP53-200 BYP54-200 200
BYP53-300 BYP54-300 300
BYP53-400 BYP54-400 400
BYP53-500 BYP54-500 500
BYP53-600 BYP54-600 600
BYP53-700 BYP54-700 700
Repetitive
peak
reverse
voltage
BYP53-800 BYP54-800
V
RRM
800
V T
c
= 140°C
Forward current, arithmetic value I
FAV
25 A
425
half-sine wave,
≤ 10 ms
Surge forward current I
FSM
350
A
T
J
= 175°C half-sine
wave, ≤ 10 ms
900
half-sine wave,
≤ 10 ms
Maximum rated value ∫i²dt
780
A²s
T
J
= 175°C half-sine
wave, ≤ 10 ms
Repetitive peak forward current I
FRM
= π*I
FAV
79 A f = >15 Hz
Effective forward current I
FRMS
45 A
Junction temperature T
Jmax
175 °C
Storage temperature range T
stg
- 50 to + 140 °C
