Diodes BAS70LP - Manual (Page 3)

BAS70LP
Document number: DS35105 Rev. 2 - 2
3 of 4
www.diodes.com
March 2011
© Diodes Incorporated
BAS70LP
NEW PROD
UC
T
0.0001
0.001
0.01
0.1
1
10
100
0 10 20 30 40 50 60 70
Fig. 3 Typical Reverse Characteristics
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
I
, I
N
ST
ANT
A
NE
OUS RE
VERSE
CURRENT
(µA)
R
T = 25°C
A
T = 85°C
A
T = 150°C
A
T = 125°C
A
0
1
10
0 8 16 24 32 40
V , DC REVERSE VOLTAGE (V)
R
C,
CAP
A
CIT
A
NCE (
p
F
)
f = 1MHz
Fig. 5 Forward Current Derating Curve
0
10
20
30
40
50
60
70
80
25 50 75 100 125 150 175
T , AMBIENT TEMPERATURE (°C)
A
I
,
A
VERA
G
E F
O
RW
AR
D CURREN
T
(
m
A)
F(A
V
)
Note 4
0 7 14 21 28 35 42 49 56 63 70
Fig. 6 Operating Temperature Derating
V , DC REVERSE VOLTAGE (V)
R
0
25
50
75
100
125
150
T
, D
E
R
A
T
ED AM
BI
EN
T
T
EM
P
E
R
A
T
U
R
E (
°C
)
A
Package Outline Dimensions
DFN1006-2
Dim Min Max Typ
A 0.47 0.53 0.50
A1 0 0.05 0.03
b 0.45 0.55 0.50
D 0.95 1.075 1.00
E 0.55 0.675 0.60
e - - 0.40
L 0.20 0.30 0.25
R 0.05 0.15 0.10
All Dimensions in mm
L
E b
R
e
D
A1
A
