BAT1000
Document number: DS30245 Rev. 10 - 2
3 of 4
www.diodes.com
July 2013
© Diodes Incorporated
BAT1000
0.01
0.1
1.0
10
0.2 0 0.4 0.6 0.8 1.0
I,
I
N
S
T
AN
T
AN
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 1 Typical Forward Characteristics
F
C
,
T
O
T
A
L
C
A
P
A
CI
T
A
NCE (
p
F
)
T
V , DC REVERSE VOLTAGE (V)
Fig. 2 Total Capacitance vs. Reverse Voltage
R
1,000
1.0
10
100
0 5 10 15 20 25
0
0.25
0.50
0 50 100 150
I,
A
V
E
R
A
G
E
R
E
C
T
IF
IE
D
C
U
R
R
E
N
T
(A
)
O
T , TERMINAL TEMPERATURE ( C)
Fig. 3 Forward Current Derating Curve
T
°
0.75
1.0
25 75 125
25
50
75
100
125
150
1 10 20 50 40 30
T
, D
E
R
A
T
E
D
AMBI
EN
T
T
EM
P
E
R
A
T
U
R
E (
)
A
ºC
V , DC REVERSE VOLTAGE (V)
Fig. 4 Operating Temperature Derating
R
R = 300°C/W
Note 6
JA
Note: 8. Assumed application thermal conditions. R θJA varies depending on application.
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
SOT23
Dim Min Max Typ
A 0.37 0.51 0.40
B 1.20 1.40 1.30
C 2.30 2.50 2.40
D 0.89 1.03 0.915
F 0.45 0.60 0.535
G 1.78 2.05 1.83
H 2.80 3.00 2.90
J 0.013 0.10 0.05
K 0.903 1.10 1.00
K1 - - 0.400
L 0.45 0.61 0.55
M 0.085 0.18 0.11
 0° 8° -
All Dimensions in mm
A
M
J L
D
F
B C
H
K
G
K1
