SCHOTTKY BARRIER RECTIFIERS APD140

Data Sheet

2

Aug. 2011 Rev. 1. 7

BCD Semiconductor Manufacturing Limited

Parameter Symbol

Value

Unit

Maximum Repetitive Reverse Voltage

V

RRM

40

V

Maximum DC Blocking Voltage

V

DC

Maximum RMS Voltage

V

RMS

28

V

Average Rectified Forward Current
0.375 " (9.5mm) Lead Length (See Figure 3)

I

F(AV)

1.0

A

Non-Repetitive Peak Forward Surge Current
8.3ms Single Half Sine-wave on Rated Load

I

FSM

35

A

Voltage Rate of Change (Rated V

R

)

dv/dt

10000

V/

µS

Operating Junction Temperature Range

T

J

-65 to 125

o

C

Storage Temperature Range

T

ST

-65 to 150

o

C

Absolute Maximum Ratings

(T

A

=25

o

C, unless otherwise noted) (Note 1)

Package

Temperature

Range

Part Number

Marking ID

Packing

Type

Lead Free

Green

Lead Free

Green

DO-41

-65 to 125

o

C

APD140VD-E1

APD140VD-G1

D140VD

140VDG

Bulk

APD140VDTR-E1

APD140VDTR-G1 D140VD

140VDG

Ammo

DO-214AC

-65 to 125

o

C

APD140VRTR-G1

140VRG

Tape & Reel

Circuit Type

Package
VD: DO-41

E1: Lead Free

APD140 -

TR:

Blank: Bulk

Ordering Information

Tape & Reel or Ammo

Note 1: Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to the device.
These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated
under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Maximum Ratings" for extended periods
may affect device reliability.

G1: Green

BCD Semiconductor's Pb-free products, as designated with "E1" suffix in the part number, are RoHS compliant. Products with
"G1" suffix are available in green packages.

VR: DO-214AC
