BAT760
Document number: DS30498 Rev. 7 - 2
3 of 4
www.diodes.com
October 2010
© Diodes Incorporated
BAT760
0
50
60
40
30
20
10
0 10 15 5 20
C
,
T
O
T
AL
C
A
P
A
C
IT
A
N
C
E (
p
F
)
T
V , DC REVERSE VOLTAGE (V)
Fig. 3 Total Capacitance vs. Reverse Voltage
R
f = 1MHz
0
0.5
1.0
0 50 100 150
I,
A
V
E
R
A
G
E
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F(
A
V
)
T , TERMINAL TEMPERATURE ( C)
Fig. 4 Forward Current Derating Curve
T
°
1.5
2.0
25 75 125
Package Outline Dimensions
Suggested Pad Layout
SOD-323
Dim Min Max
A 0.25 0.35
B 1.20 1.40
C 2.30 2.70
H 1.60 1.80
J 0.00 0.10
K 1.0 1.1
L 0.20 0.40
M 0.10 0.15
α 0° 8°
All Dimensions in mm
Dimensions Value (in mm)
Z 3.75
G 1.05
X 0.65
Y 1.35
C 2.40
Z
X
C
G Y
K
L
M
J
C
H
B A
